The general data

Model presentation

Here internal device Renault 19 is represented. It is easy to consider, where the basic knots Renault 19 are located

Renault 19 has been developed as a result of performance of program Х53 on creation of the car of the European middle class “М1”. Project realisation passed under the motto “Cars — in a life” and has occupied 42 months. Works on model creation have begun in November, 1984, and already after eight months, in July, 1985, the external design of the car has been definitively confirmed. During the following of 5 months the instrument panel has accepted the finished form. In April, 1986 works on internal furnish have been finished. Before start in a series in France in May, 1988, with a view of check and acknowledgement of correctness of the applied technical decisions, model pre-production models already наездили on ranges of 7,5 million kilometres.

Body

Design Renault 19 has been developed by firm “Reno design” (“Renault Design”) in close cooperation with known Italian designer Dzhordzhio Dzhiudzharo. One of the primary goals put before designers and engineers, was to create the car with the best aerodynamics. Release, first of all, the sports version of model subsequently to use feature of a suspension bracket, brakes and aerodynamics of a body for serial models was planned.

Renault 19 with the smooth contours is "the thoroughbred" car, whose style was created on the basis of tests in a wind tunnel. So, the size of factor of resistance of air With х is equal 0,31 (With х Х And = 0,61) and is one of strengths Renault 19, and 16-klapannyj Renault 19, thanks to the brought changes in a body design (lower suspension bracket, the forward and back spoilers, the expanded thresholds of doors), has the improved indicators — the size of Sh is equal 0,30 (With х Х And = 0,59). These indicators have been reached thanks to strongly descending cowl and the inclined bent windshield, and also successful configuration of forward headlights and a bumper with the integrated spoiler. The wings convex and slightly increased on width, and also highly lifted back part of a body with the integrated spoiler, in turn, promote improvement of aerodynamic characteristics. The drains shipped in a roof and the external mirrors possessing good aerodynamics are with that end in view applied also.

34 % of metal of a body in Renault 19 are processed in the next way:

  • It is executed unilateral оцинковка doors, the bottom cross-section basic beam of a windshield, a dividing wall of heating, an external part of a bumper, the bottom cross-section basic beam behind, and also other parts of the bottom of a body.
  • It is done bilaterial оцинковка acting parts of a cowl and a radiator for protection against abrasive influence of sand and a dirt.
  • It is executed цинксодержащее a covering of wings.

The engine and transmission

The engine is located cross-section in front with an inclination in 12 ° back in the right part of a motor compartment (if to look in the direction of travel). To the left of it the transmission settles down. Petrol engines fasten on an auxiliary frame on three points of support (two in front, one behind). To it the bottom cross-section levers of a suspension bracket also fasten. Diesel engines, unlike petrol, fasten in a motor compartment on a shaking suspension bracket which provides the improved noise isolation of the engine. This fastening provides effective suppression of vibration idling, decrease in noise of the engine on high turns and protects the engine from jolting at driving on bad road.

Transmission

All updatings Renault 19 are equipped by transmissions of manufacture of "Reno" of type JB. It is a question of the transmission located cross-section with the easy metal case. Depending on model the transmission has 4 (type JBO) or 5 (type JB3) speeds. Transmission JB3 is calculated on higher twisting moment. Both types of transmissions are equipped by blocking of casual inclusion of transfer of a backing.

Suspension bracket

Suspension bracket Renault 19 strongly differs from suspension bracket Renault 21 and is more reliable. The forward suspension bracket consists of Mak Fersona leaning against cross-section shaking levers racks.

Longitudinal directing energies are taken up by the cross-section stabilizer. From above racks of the shock-absorber of Mak Fersona fasten by means of an elastic suspension bracket to a casing of wheel arches.

Depending on engine Renault 19 it is equipped with two various types of a back axis:

  • Models with engines capacity to 65 kw have one торсион, built in a pipe of the back bridge with the cross-section stabilizer. The group of a suspension bracket of this type consists of two is longitudinal the shaking levers fastening to a body by means of directing pipes. This design of an axis was applied on other models "Reno" and has been improved for Renault 19.
  • Models with engines capacity of 65 kw and have four торсиона from which two carry out function of stabilizers more. At this type both suspension brackets of the longitudinal shaking lever are connected among themselves by a cross-beam. This design of an axis was used in various sports models "Reno".

Passive safety

  • Already mentioned auxiliary frame provides necessary safety at a head-on collision. It fastens in four points to forward longerons, and to it the radiator, longitudinal levers of a suspension bracket and steering transfer accordingly fasten.
  • Updatings of model GTX and TXE (with 5/92RT) at will are completed with antiblocking system. It is a question of the antiblocking system of the third generation which are let out by firm Bendiks (Bendix). It along with ventilated forward disk brakes includes as well double, working depending on loading, terminators of brake effort on back brakes.
  • Since November, 1992 Renault 19 at will could be completed by an air cushion of safety for the driver and натяжителем a belt for the forward passenger.

The safety air cushion settles down in a steering wheel. The electronic sensor control estimates force of blow in case of failure and ignites a gas-forming charge which inflates a safety pillow. For effective protection of the driver fastened by a seat belt the pillow volume makes about 35 l. It is filled with nitrogen for 25 m with the ambassador of ignition of a gas-forming charge. Nitrogen as the basic component of air which we breathe, is completely safe for the person and environment.

Натяжитель a belt in case of collision instantly lets out about 70 mm of a seat belt. At front blow the sensor control puts in action the small gas generator leaving from which gas взрывообразно influences during a fraction of a second the piston in the cylinder. The piston is connected to the seat belt lock in such a manner that at influence on the lock stretches and the seat belt connected with it.

At a side-winder or behind a safety pillow, натяжитель a belt do not work.
